After-sales Service Provided:Engineers available to service machinery overseas
Raw material:Low carbon steel and low alloy constructional steel
Plate width:1250x3mm
Thickness:0.5-3.0mm
Color:Blue
Packaging & Delivery
Packaging Details:
Waterproof and seaworthy plywood case
Delivery Detail:
Shipped in 45 days after payment
Type of Slitting machine and Parameter
No.
Specification (mm)
Plate Thickness (mm)
Plate Width (mm)
Weight of the Coil (T)
Shear Motor （KW)
Crimp Motor (KW)
Width of finished mm
No. Of Shear
Shear Speed (m/min)
Area（m2)）
Cutter shaft Diameter (mm)
1
1250X3
0.5-3.0
700-1250
25
55(1000r/min)
55(1000r/min)
＜40
≤10
120
21X11
220
2
1250X4
0.5-4.0
700-1250
25
55(1000r/min)
75(1000r/min)
＜40
≤10
120
21X11
220
3
1250X6
0.5-6.0
700-1250
25
75(1000r/min)
90(1000r/min)
＜40
≤10
120
21X11
220
4
1600X3
0.5-3.0
900-1600
30
75(1000r/min)
75(1000r/min)
≥40
≤13
120
21X11
240
5
1600X4
0.5-4.0
900-1600
30
75(1000r/min)
90(1000r/min)
≥60
≤13
110
21X11
260
6
1600X6
1-6
900-1600
30
45(1000r/min)
132(1000r/min)
≥60
≤10
100
21X11
260
7
2000X8
2-8
900-2000
35
75(1000r/min)
160(1000r/min)
≥70
≤6
60
30X11
300
8
2200X10
3-10
900-2200
35
75(1000r/min)
200(1000r/min)
≥80
≤5
50
35X11
320
9
2200X12
3-12
900-2200
35
160(1000r/min)
160(1000r/min)
≥100
≤5
40
38X11
320
10
2500X16
4-16
900-2500
35
185(1000r/min)
250(1000r/min)
≥100
≤5
40
38X11
400
11
2500X20
6-20
900-2500
35
250(500r/min)
250(500r/min)
≥100
≤4
30
38X11
480
company profile
As a leading and professional manufacturer of welded pipe forming machinery and related production in china, Hebei Tengtian welded pipe equipment manufacturing Co., Ltd. Has 16 year’s experience in ERW pipe making field ,Tengtian factory covers 50000square meters and has advanced equipments We has introduced advanced modern manager system to guarantee the production quality.
With a long time experience we have more profound understand toward user’s need.
With enterprise grow up we can supply all range of welded pipe forming machinery from single machine to completed pipe mill production line,we also supply “turnkey project” system solution for our customers from all over the world ,including to upgrade old system ,completed after-sale service,test running and worker training service .
Insisting on the principal of “ Quality first, Customer first” Our products are selling well in south America, Southeast Asia, Africa, Australia, Russia,South Korea etc.
We welcome all customer visit our factory , we will offer to our clients the best suitable technical solution and best reasonable price.
Our Services
1.supply all the operation manual and video clip going with machinewe
2.supply free training about each epuipmen here in our plant until you know clearly about the technical operation
3.we can send technicians to your site for installation and training, but dear friend,the relevant should be borne by your company in our first coopration.
